SMALL LOTS DYEING MACHINE

SP/260

Small lots dyeing machine to dye yarns, hanks, fabrics, tops, zippers, ribbons, loose fibre.

High pressure, high temperature (140 °C,

6 bar) working in fully flooded mode with static (pressure pump) and expansion tank, modular construction up to 6 individual vessels, with upgrading possibility.

All possible coupling connections between the kiers.

Kiers dimensions at customer request to dye from 1kg to 12 kgs of material with this model.

Machine suitable to dye small lots of material with high reproducibility and high right first time and color quality.

Liquor ratio from 1:6 to 1.20.

Steam or electric heating, water cooling.

Material carrier for yarn in pkgs, fabric in beam, narrow fabrics, tops, loose fibres.

Analog control of filling volume, 3% tolerance. Small volume stainless steel pump, equipped with inverter, especially designed to dye soft and hard materials simply changing rpm and maintaining flow constant.

Expansion tank with fast drain and rinsing and analog level to have perfect volume control.

Flow rate automatic control. DP automatic control.

Fast low temperature drain. High temperature drain.

Overflow rinsing from top of the lid. Air squeeze avaiable.

100% stock tank heated and mixed with fast injecting and draining and analog level.

Multiple water inlet.

Machine can be fitted with all kind of controllers or industrial PC.

All dyeing functions are fully automatic.
