Press for big carriers. Construction in painted iron with a column anchored to the wall, mobile arm with carriage. The piston is loaded in the carriage. The arm can also rotate.

Gear motor with self-braking for carriage with piston movement with limit switch. Electric panel placed on the wall with 2 handed safety commands for the piston movement.

A press suitable for single spindle carriers for small machines is available.



Press from height about 2100 mm to 700 mm. Colum dimensions 3000 mm.

Rotating arm length: 2000 mm. Max piston’s run: 1.4 mt.

Air pressure regulator with manometer from

0.5 to 8 bar.

Selector for 3 kind of different pressures. Two handed operation to move the piston to press.
